XRPB-1 Mechanical Powder Compacting Press (for magnetic materials)

Precision Powder Press for Magnetic Materials. Engineered for uniform density, stable magnetic performance, and high-efficiency production of ferrite and magnetic components.

Featuring a fully enclosed self-lubrication system, pneumatic clutch and brake with high stopping accuracy, and a floating intermediate die, it enables three-step segmented density control to ensure uniform magnetic properties.

Categories: Mechanical Powder Press

Features

Why XIRO machinery ?

Specification

This table only lists partial parameter configurations for reference. For more parameter configurations, please feel free to inquire.

Item	Technical Specification
Model	6T	20T
Rated Compaction Force	60 kN	200 kN
Ejection Force	30 kN	100 kN
Die (Middle Die) Load Capacity	40 kN	200 kN
Upper Punch Stroke	80 mm	90 mm
Upper Punch Adjustment Range	40 mm	40 mm
Fill Depth	60 mm	45 mm
Ejection Stroke	40 mm	30 mm
Powder Feed Adjustment Stroke	5 mm	5 mm
Middle die face adjustment range	±10 mm	±10 mm
Die Set Accuracy	Platen parallelism and guide pillar perpendicularity within 0.01 mm
Forming Speed	12–40 SPM	12–45 SPM
Overload / Underload Protection	Mechanical load cell	Hydraulic load cell
Clutch System	Pneumatic clutch–brake combination	Pneumatic clutch–brake combination
Lubrication Method	Internal circulating pressure lubrication	Internal circulating pressure lubrication
Powder Feeding System	Cam-driven linear feed	Cam-driven linear feed
Powder Hopper Capacity	8 L	10 L
Angle Controller	Absolute encoder 720 (accuracy ±0.5°)	Encoder 360
Operation Modes	Jog, Continuous, Stop, Emergency Stop, Reverse, Powder Detection Switch, Production Counter, Production Ratio Counter, Pressure Monitoring Switch
Main Motor Power	3.7 kW	4 kW
Air Consumption	10 L/min	15 L/min (Upper-1 / Lower-2 full functions enabled)
Power Supply	380 V @ 50 Hz (or as customer request)	380 V @ 50 Hz (or as customer request)
Control Voltage	DC 24 V	DC 24 V
Tooling Structure	Upper-1 / Lower-2 configuration	Upper-1 / Lower-2
Floating Core Rod	Included	Included
Machine Weight	Approx. 1.2 T	Approx. 1.2 T
Overall Dimensions (W × D × H)	1200 × 1350 × 2640 mm	1200 × 1350 × 2640 mm
Die Set Specifications (Upper-1 / Lower-2 Configuration)		Die Set Specifications (Upper-1 / Lower-2 Configuration)
Upper Punch Load Capacity	60 kN	Upper Punch Load Capacity	200 kN
Die (Middle Die) Load Capacity	40 kN	Lower Punch Fill Adjustment	30 mm
Lower Floating Punch Load Capacity	40 kN	Lower Punch Step Height Adjustment	15 mm
Lower Second Fixed Punch Load Capacity	60 kN	Lower Punch Pressure	150kN
Lower Floating Punch Fill Adjustment	30 mm	Fixed Punch Pressure	200kN
Lower Floating Punch Step Height Adjustment	15 mm	Movable Core Rod Adjustment	±5 mm
Movable Core Rod Adjustment	±5 mm	Floating Core Rod Stroke	35 mm
Floating Core Rod Stroke	10 mm	Weight	Approx. 130 kg
Core Rod Fill Adjustment	5 mm
Core Rod Step Height Adjustment	5 mm
Tooling Weight	Approx. 60 kg
